Eazy Riderz

RFN Rally Pro

RFN Rally Pro

£4,499.99 GBP
£4,499.99 GBP
Sale Sold out
Taxes included.

NEW ARRIVAL!!!!

RFN Rally Pro: The ultimate off-road adventure bike. A powerful adventure bike with long-travel suspension and rally-inspired features, this bike is ready to tackle any terrain.

RANGE 100 mi (MAX)

PEAK POWER 12.5 kW

KERB WEIGHT 68kg

BATTERY 43 Ah

SHOCK ABSORBERS 200 mm

Maximum torque 270 N.m

Specification

Battery
74V 43Ah / 2590 Kwh, LG Premium 21700 lithium cells, can be removed to charge in or out of the bike.
Brakes
Front and Rear 4-piston calipers, using DOT 4 fluid and 210 mm x 2.3mm floating discs.
Charging
3 hours charge time. (10A charging. From 0-100%)
Controller
Sine wave, Best-in-class power density and state-of-the-art motor control algorithms.
Waterproof
IP67

Drivetrain

Electric Motor

Air cooled 3-Phase PMSM (Permanent Magnet Synchronous Motor) motor, Regeneration as standard, Direct Drive, 13T Front Sprocket, 420 chain.

Sprocket
58T
Rated power
5 kW
Peak power
12.5 kW
Max Torque of motor
58 N·m
Max Torque of rear wheel
270 N.m

Dimensions

Fork angle
24 °
Ground clearence
340 mm
Offset
15mm at the triple clamps, 45 mm at the axle.
Seat height
860 mm
Trail
111 mm
Wheel base
1330 mm

Bodywork

Fenders & Bodywork
PP/ABS plastic
Frame
6082 aluminum extruded, forged, CNC machined and steel frame.
Front suspension
Upside Down, 200 mm travel, Fully adjustable
Handlebar
High rise 6061 aluminium, 22mm width, 760mm length
Rear suspension
240mm x 74 mm travel. Adjustable compression, rebound and preload.
Regulatory Cetificate
CE

Ride modes

Mode 1
Tortoise mode: Limited to 15 mph with 3.5h battery range.
Mode 2
Rabbit mode: Standard 5kw output, 1-2 h riding time.
Mode 3
Rocket mode: 60 seconds of 12.5Kw output. 1 hour riding time.
Mode 4
Reverse mode: Limited to 6 mph

Speed & Range

Range
100 mi (Test data Load: 75 Kg, 12.5 mph uniform speed, ambient temperature: 25 °C, flat pavement, standard tyres, standard tyre pressure)
Top speed
60 mph (depending on gearing and conditions)

Weight

Net weight of Battery
15 kg
Net weight of whole bike (Including Battery)
68 kg
Maximum load
120 kg

Wheels & Tyres

Hubs
Forged and CNC aluminium hubs.
Rims
F 19"/ R 18" re-inforced 7050 aluminium.
Tyres
F CST 70/100-19, R CST 90/100-18 MX tyres for maximum grip off road.
